Learn more about the Lenovo W520 (427637U)

8GB RAM Memory for IBM-Lenovo ThinkPad W520 (4 Slots) (DDR3-12800) - Laptop Memory Upgrade OFFTEK Part Number:-FT8GSK64V4U-1060269 Capacity:-8GB Module Form Factor:-204 Pin SoDimm Memory Type:-DDR3 Bandwidth:-DDR3-12800 (PC3-1600) Memory Specs:-204 Pin 1.5v DDR3 PC3-12800 SoDimm Premier Brand Memory. Lenovo ThinkPad W520 427638U laptops technical specifications database. Number of Total Memory Slots: 4. Memory Card Reader: Yes. Network Lenovo ThinkPad W520.

Model
Brand	ThinkPad
Series	W Series
Model	W520 (427637U)
Part Number	427637U

Quick Info
Operating System	Windows 7 Professional 64-Bit
CPU	Intel Core i7-2720QM 2.2GHz
Screen	15.6'
Memory	8 GB DDR3
Storage	500 GB
Optical Drive	DVD±R/RW
Graphics Card	NVIDIA Quadro 1000M
Video Memory	2 GB
Communication	Modem, Gigabit LAN and WLAN
Dimensions (W x D x H)	14.68' x 9.65' x 1.29'-1.44'
Weight	5.75 lbs.
Other Features	Fingerprint reader Intel Active Management Technology (iAMT)

Lenovo ThinkPad W520 42844CU laptops technical specifications database. Number of Total Memory Slots: 4. Memory Card Reader: Yes. Network Lenovo ThinkPad W520. The W520 comes in 4 quad-core configurations, and 1 dual-core configuration. The quad-core configurations support RAM up to 32GB. It is similar to the T520 model but supports more powerful CPU's and GPU's and has 4 RAM slots (32GB total).

CPU
CPU Type	Intel Core i7 2nd Gen
CPU Speed	2720QM (2.20 GHz)
Core Name	Sandy Bridge
CPU Support	6MB L3 Cache

Chipset
Chipset	Intel QM67

Display
Screen Size	15.6'
Wide Screen Support	Yes
Resolution	1920 x 1080

Operating System
Operating System	Windows 7 Professional 64-Bit

Graphics
GPU/VPU	NVIDIA Quadro 1000M
Video Memory	2 GB
Graphic Type	Dedicated Card

Storage
HDD	500 GB
HDD RPM	7200 RPM
HDD Interface	SATA

Memory
Memory	8 GB
Memory Speed	DDR3 1333
Memory Spec	4 GB x 2
Memory Type	204-Pin DDR3 SO-DIMM
Memory Slot (Total)	4
Memory Slot (Available)	2
Max Memory Supported	32 GB

Optical Drive
Optical Drive Type	DVD±R/RW
Optical Drive Spec	DVD burner, 12.7mm Ultrabay Enhanced, removable

Communications
Modem	V.92 56K
LAN	10/100/1000Mbps
WLAN	802.11a/b/g/n Wireless LAN
Bluetooth	Bluetooth 3.0 wireless, LED indicator

Ports
Card Slot	1 x ExpressCard/34
USB	Two USB 3.0 (blue), one Powered USB 2.0 (yellow), one USB 2.0/eSATA combo port
IEEE 1394	IEEE 1394 FireWire 400 (4-pin connector; 1394a-2000 standard)
Video Port	1 x VGA, 1 x DisplayPort

Audio
Audio	High Definition (HD) Audio, Conexant 20672 codec
Speaker	Stereo speakers, 1 watt x 2

Input Device
Touchpad	ThinkPad UltraNav
Keyboard	7 row, 89-key, ThinkVantage button, spill-resistant, multimedia Fn keys
Pointing Stick	TrackPoint pointing device
Webcam	HD 720p
Card Reader	4-in-1 reader (MMC, SD, SDHC, SDXC)

Power
Battery	9-cell Lithium Ion

Dimensions & Weight
Dimensions (W x D x H)	14.68' x 9.65' x 1.29'-1.44'
Weight	5.75 lbs.

Features
Package Type	Commercial

Additional Information
Date First Available	November 29, 2011

ThinkPad W520

This page gives an overview of the ThinkPad W520.

Standard Features

One of the following processors:
- Intel Quad Core i7-2920XM (2.50GHz, 8MB L3, 1600MHz FSB, 55W)
- Intel Quad Core i7-2820QM (2.30GHz, 8MB L3, 1600MHz FSB, 45W)
- Intel Quad Core i7-2760QM (2.40GHz, 6MB L3, 1600MHz FSB, 45W)
- Intel Quad Core i7-2720QM (2.20GHz, 6MB L3, 1600MHz FSB, 45W)
- Intel Dual Core i7-2620M (2.70GHz, 4MB L3, 1333MHz FSB, 35W)
- Intel Dual Core i5-2540M (2.60GHz, 3MB L3, 1333MHz FSB, 35W)
- Intel Dual Core i5-2520M (2.50GHz, 3MB L3, 1333MHz FSB, 35W)
One of the following discrete graphics cards:
- NVIDIA Quadro 1000M with 2GB DDR3 and 96 CUDA cores, and with Optimus™ Technology
- NVIDIA Quadro 2000M with 2GB DDR3 and 192 CUDA cores, and with Optimus™ Technology
One of the following TFT displays:
- 15.6' TFT display with 1366x768 (HD) resolution with LED backlight
- 15.6' TFT display with 1600x900 (HD+) resolution with LED backlight
- 15.6' TFT display with 1920x1080 (FHD) resolution with LED backlight
2GB, 4GB or 8GB DIMMS PC3-10600 memory standard
- 2 DIMM slots on dual-core models (up to 16GB)
- 4 DIMM slots on quad-core models (up to 32GB)
- Samsung M471B5273DH0-CH9 4 GB DDR3-1333 SDRAM (8-8-8-22 @ 609 MHz) (7-7-7-20 @ 533 MHz) (6-6-6-17 @ 457 MHz) (5-5-5-14 @ 380 MHz)
One of the following storage options:
- 320GB 7200rpm 2.5' SATA HDD
- 500GB 7200rpm 2.5' SATA HDD
- 128GB Samsung SATA SSD
- 160GB Intel SATA SSD
Intel HD Audio with a CX20585 codec
Ultrabay Enhanced with one of the following:
MiniPCI Express slot 1 with one of the following:
- Thinkpad b/g/n
- Intel Centrino Advanced-N 6205 (2x2 AGN)
- Intel Centrino Ultimate-N 6300 (3x3 AGN)
MiniPCI Express slot 2 with one of the following:
- None (empty)
- Sierra Wireless MC8355 Gobi 3000 WWAN
- Ericsson F5521gw WWAN
- LeadCore LC5730D WWAN
- Huawei EM660 WWAN
- Intel 310 mSATA SSD
Lenovo Integrated Smart Card Reader (Optional)
720p Integrated camera on select models
Huey PRO Colorimeter by X-Rite on select models
Integrated Fingerprint Reader on select models
ThinkPad Bluetooth with Enhanced Data Rate (BDC-3.0) on select models
UltraNav (TrackPoint / Touchpad combo)
Firewire 400 (IEEE1394a)
Intel Active Management Technology (AMT) on select models

Hardware W520-4284-49G

Resources

Reviews

StorageReview.com, 2011-06-10
Keith Combs' Blahg, 2011-03-28

Linux Installation

Installation of Fedora 14 on a ThinkPad W520
Installation of Fedora 15 on a ThinkPad W520
Installation of Debian Squeeze on a ThinkPad W520
Installation of Debian Wheezy on a ThinkPad W520
Installation of Slackware 13.37 on a ThinkPad W520 updated 7/21/2011
Installation of OpenSuse11.4 on a ThinkPad W520
Installation of Ubuntu 11.04 on a ThinkPad W520

Power Adapter

The W520 comes with a special 170W AC adapter (P/N 0A36227) that is currently not shipped with any other Thinkpad. Note that it is different from the W700 170W AC adapter (P/N 41R4421). The W520 AC adapter is larger but lighter than the W510 135W AC adapter. (Maybe not always? In a comparison of a 135W adapter that came with a W510 and a 170W adapter that came with a W520, the 170W was not only larger but also about 100g heavier.)

The 170W adapter plug has two extra notches that makes it physically impossible to use the 170W adapter with older equipment such as the W510 and some docking stations, although older chargers are physically forward compatible (while they may not provide enough power) with ports that support the 170W adapter.

Most newer (20V) Thinkpad AC adapters have a compatible plug with the W520, but not all of them will work due to power constraints. The following table shows which AC adapters can be used to run the W520:

Marketing P/N	Rated power	Works on W520	Charge while off	Comment
0A36227	170W	yes	yes	Official AC adapter for W520
41R4421	170W	no	no	Official AC adapter for W700, different plug diameter
55Y9317	135W	yes	yes	Official AC adapter for W510.
Various	90W	no	yes	Battery continues to drain, does not work
Various	65W	no	yes	Battery continues to drain, does not work

The 135W adapter is sufficient to run the W520 without throttling. The 65W and 90W adapters can only be used to charge the battery while the W520 is not running, that is, powered off, hibernated, or suspended.
